- 4.3inch portable multifunctional monitor& satellite finder is a product for the installation of satellite TV test tools. Set the satellite TV signal and image shows test, radio, television, monitoring function. With auto scan/blind scan/TP scan .Using TFT LCD display image, LED backlighting with low power consumption. And build-in large capacity with high-performance lithium battery for the integration of high-tech electronic products.
- Low power consumption LED / high-resolution digital display TFT LCD. It has built-in 2600mAh Li-lon battery. If don’t need an external power then it can keep on working around 3-4 hours, with DC12V output (use of camera); AV output and input function; Satellite images and signal quality can be displayed through the LCD; Unique star search guidance function; Build-in LNB management circuits for TV tuner, receive satellite signal alarm (search satellite signal quality changeable warn and alarm, support DVB-S/S2&MPEG-4 image & signal for free program and warming). 13V18V/22K signal lock indicator which located at the panel can show in the same time. This finder used the portable structure, with small in size and light in weight. Equipped with installation tool backpack, it is more convenient to carry, so it is the professional equipment for satellite TV receiver system engineering and control engineer technicians.
- Built-in satellite signal warning; Find star signal quality LED displayed, with DC12V output.
- Easy Satellite Manager (EDIT, delete and SCAN), Edit TP, Frequency, LNB switch, Symbol Rate etc
| Specification |
LCD Display |
4.3”TFT LCD |
Display size:97*55mm(16:9 display) |
| Dots pixels:480*272(391680Pixes) |
| Satellite signal |
video decoding |
DVB-S/S2,MPEG-2/4 display |
| signal test |
DVB-S/S2,MPEG-2/4,signal alarm & signal test. |
| Menu language |
English,French,Deutsch,Italiano;Spanish;Portuguese;Russian;Turkish;Polish; Arabic; Persian; Thai. |
| LNB/Tuner Input |
connector |
F type male puly : 75Ω(F) |
| Frequency range |
950MHz-2150MHz(DVB-S/S2) |
| Signal level |
-80~-20dBm |
| Symbol rate |
13/18V.max400mA(DVB-S/S2) |
| LNB switch control |
22KHz(turn on/off/auto) |
| DiSEqC |
1.0, 1.1, 1.2, USALS |
| Satellite Management |
Edit, Add, Delete |
| Minimum electric level |
About 35dBuV (noise) |
| Maximum electric level |
About 90dBuV |
| Demodulator |
Front end |
QPSK(SCPC and MCPC compatible) |
| Symbol rate |
2Mbps-45Mbps |
| Guard interval modes |
1/32,1/16,1/8 Active symbol duration |
| Carriers/Constellation |
All modes supported including non hierarchical |
| Demodulation |
QPSK/8PSK/16PSK |
| System Resource |
SDRAM |
1G DDR2 SDRAM |
| FLASH |
32MB NOR FLASH |
| Video Decoder |
HDMI Output |
480i /480P/576i / 576P / 720P50 /720P60 /1080i25 /1080i30 /1080P50 /1080P60 /1080P25 /1080P30 /1080P24 HD signal output. |
| Video format |
PAL/NTSC/SECAM |
| Video decoding |
MPEG-2 SD/HD(MP@ML and MP@HL), |
| MPEG-4 H 2.64/AVC SD/HD DivX 3.X~6X |
| Aspect ratio |
4:3,16:9 |
| Audio |
Audio decoding |
MPEG-1 and MPEG-2 layer I&II, Dolby Digital Audio,E-AC3,WMA and HE-AAC Digital Audio |
| Sample rate |
32kHz,22.1kHz,44.1KHz,48kHz |
| USB |
Connector |
USB upgrade, |
| media player( PVR, Video, Music, Image) |
| Power Supply |
Lithium Battery |
11.1V/2600mAh |
| Charger |
In AC100-220V Charge 13.5V/1.5A |
| Out DC12V/1.5A |
| Physical Specification |
Size |
180*122*48mm |
| Net Weight |
528g (including battery pack) |
| size |
180*122*48mm |
| weight |
0.528kg |
